3260064
| Manufacturer: | Phoenix Contact |
In Stock 0 pcs
|
|
|---|---|---|---|
| Datasheet: | 3260064 | ||
| Product Category: | Terminal Blocks - Specialized | Reference Price (In US Dollars) | 1pcs |
| Description: | TERM BLK MIDDLE 2POS 20.0MM BLK | $23.1 | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- Type
- Middle
- Length
- 3.976" (100.99mm)
- Series
- CLIPLINE PTPOWER
- Features
- -
- Part Status
- Active
- Current - UL
- 140A
- Height (Max)
- 3.780" (96.00mm)
- Voltage - UL
- 1kV
- Current - IEC
- 150A
- Housing Color
- Black, Yellow
- Mounting Type
- Direct Mount
- Voltage - IEC
- 1.5kV
- Number of Levels
- 4
- Stripping Length
- 30mm
- Terminal - Width
- 20.0mm
- Termination Style
- Push In, Spring
- Number of Positions
- 2
- Material - Insulation
- Polyamide (PA), Nylon
- Operating Temperature
- -
- Wire Gauge or Range - AWG
- 1/0-8 AWG
- Wire Gauge or Range - mm²
- 10-70mm²
- Material Flammability Rating
- UL94 V-0
